Product introduction

Cyclone dust collector is a kind of dust removal device. The mechanism of dust is the dust flow to rotate by centrifugal force to dust from the air separation and trapping in the wall, with the gravity of the dust particles into the hopper. Each part of the cyclone has a certain size, the proportions of each relationship changes, can affect the efficiency and pressure loss of cyclone dust collector, the diameter and the size of an air inlet and exhaust pipe diameter as the main factors. In use, it should be noted that when the limit exceeds a certain limit, the favorable factors can also be turned into unfavorable factors. In addition, some factors are beneficial to improve the dust removal efficiency, but increase the pressure loss. Therefore, the adjustment of the factors must be taken into account.

The cyclone dust collector is composed of an air inlet pipe, an exhaust pipe, cylinder, cone and ash composition. The cyclone dust collector has the advantages of simple structure, easy manufacture, installation and maintenance management, equipment investment and the operating cost is low, has been widely used for the separation of solid and liquid particles from the air, or the separation of solid particles from liquid. Under ordinary operating conditions, the centrifugal force acting on the particles is 5~2500 times that of gravity, so the efficiency of cyclone dust collector is significantly higher than that of gravity settling chamber. Based on this principle, a cyclone dust removal device with a dust removal efficiency of more than ninety percent has been successfully developed. In the mechanical dust collector, cyclone dust catcher is the most efficient one. It is suitable for the removal of non sticky and non fibrous dust, mostly used to remove particles more than 5 m, parallel multi cyclone dust collector, 3 ~ m particles also have 80 ~ 85% dust removal efficiency. A cyclone dust collector with high temperature resistant, corrosion resistant and corrosion resistant special metal or ceramic material can be operated under the condition that the temperature is 1000 degrees centigrade and the pressure is 500 * 105Pa. Considering the technical and economic aspects, the control range of cyclone pressure loss is usually 500 ~ 2000Pa. Therefore, the utility model belongs to a middle efficiency dust collector, and can be used for purifying high-temperature flue gas. The utility model is a dust collector which is widely used, and is used for dust removal of a boiler, multi-stage dust removal and pre dusting. Its main drawback is that the removal efficiency of fine dust particles (< 5 m) is low.

Company information

Shandong Luli medicine equipment manufacturing and installation Co. Ltd. is a company engaged in the extraction, concentration and drying engineering technology development of high-tech enterprises, specializing in the extraction, concentration and drying technology and equipment research and development, design, manufacture, installation, commissioning and technical consultation!
